Exhibition Hall GOB Mini LED Display With Alum Cabinet FCC Certificated

Exhibition Hall GOB Mini LED Display With Alum Cabinet FCC Certificated

Exhibition Hall GOB Mini LED Display

P1.875 SMD GOB Mini LED Display

Alum Cabinet GOB Mini LED Screen

Exhibition Hall GOB Mini LED Display With Alum Cabinet FCC Certificated Images

Product Categories

Shenzhen LCS Display Technology Company., Ltd

Contact Now

Name: Exhibition Hall GOB Mini LED Display With Alum Cabinet FCC Certificated
Brand: SMART LED
Price: 100.00 USD

Buy cheap Exhibition Hall GOB Mini LED Display With Alum Cabinet FCC Certificated product

Brand Name : SMART LED

Model Number : P1.875

Certification : CE ,FCC,CCC

Place of Origin : China

MOQ : 100pcs

Price : 100.00 usd

Payment Terms : T/T

Supply Ability : 3000pcs

Delivery Time : 5days

Packaging Details : 580*370*400mm

Item : P1.875 MINI LED Module GOB

Cabinet Size : 600mm*337.5mm

Resolution : 320*180

Driving Method : 1/32 Scan

LED Lamp : SMD 1515

Dot Density : 284444

Refresh Rate : 3840hz

Power : 144W

Contact Now

Exhibition Hall MINI LED Display1.25mm Pixel Pitch SMD Alum Cabinet GOB 600mm*337.5mm FCC Certificated Shenzhen Factory

INDOOR P1.875 SMD 3IN1 TECHNICAL PARAMETERS

Unit Module	Item	Parameter
	Model Number	LCS-P1.875-30S
	Module size	150mm*168.75mm
	Pixel pitch	1.875mm
	Pixels Density	284444/m2
	Pixel configuration	1R1G1B
	Package mode	SMD-1515
	Pixel resolution	80dots(W)*180dots(H)
	Max Power	30W
	Module thickness	1.8mm
	Weight	0.45KG
	Drive type	Constant drive
	Scan mode	1/30scan
	Port type	HUB76D
	Brightness of white balance	≥600cd/㎡
box	Size	600mm*337.5mm

LED Cabinet	Dimension	600mm*337.5mm
	Monomer Module Number	4pcs
	Power supply	5V/60A*1 pcs
	Pixel per cabinet	320*180
	Best viewing distance	2M～10M
	Best viewing angle	140°(W) 140°(H)
	Temperature	storage:-35℃～+85℃ working:-20℃～+50℃
	Relative humidity	10%-75%
	Thickness	63mm

Power	Working voltage	AC220V±10%
	Average Power consumption	<500W/㎡
	Max.Power consumption	<1250W/㎡
	Current	<15mA(single LED)
Control system	CPU	Pentium4 or above
	Operation system	WIN98/2000/NT/XP/WIN7
	Control method	ynchronization
Main technical parameter	Driving device	Constant drive IC
	Refresh frequency	>3840HZ
	Grey scale/colors	65536gray level/16.7M colors
	MTBF	>9000hours
	Power switch	Automatic switch
	Display Mode	≥1024*768

Exhibition Hall GOB Mini LED Display With Alum Cabinet FCC Certificated

Refresh:960hz & 3840hz

Exhibition Hall GOB Mini LED Display With Alum Cabinet FCC Certificated

Refresh:960hz Refresh:3840hz

Project Install:

Exhibition Hall GOB Mini LED Display With Alum Cabinet FCC Certificated

Project Case:

Exhibition Hall GOB Mini LED Display With Alum Cabinet FCC Certificated

Package:

● Box size:740mm*790mm*640mm

● Package quantity:8PCS

● Weight:95Kg

Exhibition Hall GOB Mini LED Display With Alum Cabinet FCC Certificated

Web:

WWW.LEDLCS.COM

www.ledvideo-screen.com

Product Tags:

Configuration

Die case
60*480mm

GOB module

Power

connector

Power supply
CL 200W

3840Hz
16BIT灰阶
